SIEMENS PLC SIMATIC S7-1500 DQ 32X24VDC/0.5A BA (25 MM) 6ES7522-1BL10-0AA0 SAFETY-ORIENTED SHUTDOWN OF LOAD GROUPS

Brand Name : SIEMENS

Model Number : DQ 32x24VDC/0.5A BA (25 mm) 6ES7522-1BL10-0AA0

Certification : CE

Place of Origin : Germany

MOQ : 1

Price : USD

Payment Terms : L/C, T/T

Supply Ability : 100

Delivery Time : 10-12Days

Packaging Details : 15,10 x 15,40 x 4,60

Number Of Digital Outputs : Up to 64

Number Of Analog Outputs : Up to 32

Cpu Type : S7-1500

Number Of Communication Interfaces : Up to 4

Operating Temperature : 0-60°C

Memory : Up to 1 MB

Number Of Analog Inputs : Up to 32

Weight : Standard: 0.8 kg, Compact: 0.5 kg

Protection Rating : IP20

Power Supply : 24 V DC

Number Of Digital Inputs : Up to 64

Contact Now

SIEMENS PLC SIMATIC S7-1500 DQ 32X24VDC/0.5A BA (25 MM) 6ES7522-1BL10-0AA0 SAFETY-ORIENTED SHUTDOWN OF LOAD GROUPS

Product Introduction:
The SIEMENS PLC SIMATIC S7-1500 "DQ 32X24VDC/0.5A BA (25 MM)" 6ES7522-1BL10-0AA0 is a digital output module designed for the SIEMENS SIMATIC S7-1500 series. It features 32 digital output channels capable of controlling devices operating at 24VDC, with a maximum current rating of 0.5A per channel. This module is equipped with a detachable front connector (25 MM) for easy installation and maintenance.

Product Information and Specifications:
- Model: DQ 32X24VDC/0.5A BA (25 MM) 6ES7522-1BL10-0AA0
- Digital Outputs: 32 channels
- Output Voltage: 24VDC
- Maximum Current per Channel: 0.5A
- Front Connector: Detachable front connector (25 MM)

Product Attributes:
- Model: DQ 32X24VDC/0.5A BA (25 MM) 6ES7522-1BL10-0AA0
- Digital Outputs: 32 channels
- Output Voltage: 24VDC
- Maximum Current per Channel: 0.5A
- Front Connector: Detachable front connector (25 MM)

The module is safety-oriented and supports safety-related applications. It is capable of initiating a safety-oriented shutdown of load groups. This means that it can trigger a safety response or shut down specific groups of connected devices or processes to ensure the safety of personnel and equipment.

To obtain detailed information about the safety-oriented features, safety certifications, and guidelines for using this module in safety-critical applications, it is recommended to refer to the product documentation provided by Siemens or consult their technical support. They can provide specific information regarding the safety features and capabilities of the module, including the safety-oriented shutdown functionality for load groups, to ensure its proper and safe use in your application.

Product

Article Number (Market Facing Number)

6ES7522-1BL10-0AA0

Product Description

SIMATIC S7-1500, digital output module, DQ32xDC 24V/0.5A BA, 32 channels in groups of 8, 4 A per group; the module supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015. delivery incl. front connector push-in

Product family

SM 522 digital output modules

Product Lifecycle (PLM)

PM300:Active Product

Price data

Region Specific PriceGroup / Headquarter Price Group

219 / 219

List Price

Show prices

Customer Price

Show prices

Surcharge for Raw Materials

None

Metal Factor

None

Delivery information

Export Control Regulations

AL : N / ECCN : 9N9999

Estimated dispatch time (Working Days)

1 Day/Days

Net Weight (kg)

0,360 Kg

Packaging Dimension

15,40 x 20,40 x 4,00

Package size unit of measure

Quantity Unit

1 Piece

Packaging Quantity

Additional Product Information

EAN

4047623402503

UPC

887621779054

Commodity Code

85389091

LKZ_FDB/ CatalogID

ST73

Product Group

4501

Group Code

R151

Country of origin

Germany

Compliance with the substance restrictions according to RoHS directive

Since: 21.10.2013

Product class

A: Standard product which is a stock item could be returned within the returns guidelines/period.

WEEE (2012/19/EU) Take-Back Obligation

Yes

REACH Art. 33 Duty to inform according to the current list of candidates

Lead CAS-No. 7439-92-1 > 0, 1 % (w / w)

Lead monoxide (lead ... CAS-No. 1317-36-8 > 0, 1 % (w / w)

Silicic acid, lead s... CAS-No. 11120-22-2 > 0, 1 % (w / w)

4,4'-isopropylidened... CAS-No. 80-05-7 > 0, 1 % (w / w)

2-methyl-1-(4-methyl... CAS-No. 71868-10-5 > 0, 1 % (w / w)

SCIP number

36fd591b-0e2d-414c-a569-47ac9b69b043
